LV AC machinery drive module, IEC: Pn 11 kW, 23.1 A
(ACS355-03E-23A1-4)
| ABB Type Designation: | ACS355-03E-23A1-4 |
| Catalog Description: | LV AC machinery drive module, IEC: Pn 11 kW, 23.1 A (ACS355-03E-23A1-4) |
| Output Power, Normal Use: | 11kW |
| Output Current, Normal Use: | 23.1 A |
| Order Multiple: | 1 piece |
| Input Voltage (Uin): | 380 … 480 V |
| Output Current, Normal Use (In): | 23.1 A |
| Output Power, Normal Use (Pn): | 11kW |
| Frequency (f): | 50/60 Hz |
| Degree of Protection: | IP20 |
| Country of Origin: | Finland |
| Frame size | R3 |
| Product Net Weight: | 3.2 kg |
| Product Net Depth / Length: | 169 mm |
| Product Net Height: | 236 mm |
| Product Net Width: | 169 mm |
| Communication Protocol: |
MODBUS LON DeviceNet PROFIBUS CAN EtherNet/IP PROFINET IO TCP/IP Other Bus Systems |
| Number of Hardware Interfaces: | Industrial Ethernet 0 PROFINET 0 RS-232 1 RS-422 0 RS-485 1 Serial TTY 0 USB 0 Parallel 0 Other 1 |
