6SE7036-5WK20
6SE7036-5WK20 SIMOVERT MASTERDRIVES VECTOR CONTROL INVERTER CHASSIS UNIT, IP00 890-930V DC, 650 A ,NOM. POWER RATINGS: 630KW
| Parameter Item | Official Specification |
|---|---|
| MLFB Order Code | 6SE7036-5WK20 |
| Product Full Name | SIMOVERT MASTERDRIVES Vector Control DC/AC Inverter Chassis Unit |
| Cooling Type | Air-cooled compact PLUS inverter |
| Protection Class | IP00 (bare chassis, install inside control cabinet) |
| Rated DC Link Voltage | 890 – 930 V DC (±15% tolerance) |
| Nominal Output Current | 650 A |
| Nominal Rated Power | 630 kW |
| Output Frequency Range | 0 – 600 Hz |
| Standard Pulse Frequency | 2.5 kHz (adjustable 0.75–12 kHz) |
| Control Mode | Closed-loop vector control, sensorless vector, V/f control |
| Overload Capacity | 150% rated current for 60 s, base load cycle 300 s |
| Auxiliary Control Supply | External 24 V DC (20–30 V DC) |
| Standard Operator Panel | PMU basic panel; OP1S as optional upgrade |
| Expansion Slots | 6 internal slots for communication / encoder / I/O option boards |
| Supported Encoders | Incremental encoder, sin/cos encoder, analog tachometer |
| Built-in Serial Interface | USS serial communication (standard) |
| Optional Communication Cards | Profibus-DP, DeviceNet, CAN, SIMOLINK, Ethernet |
| Operating Ambient Temp | 0 °C ~ +45 °C full load; derate power above 45 °C up to +50 °C |
| Storage & Transport Temperature | -25 °C ~ +70 °C |
| Relative Humidity | 5%–85% RH, non-condensing, pollution degree 2 |
| Max Operating Altitude | ≤1000 m without power derating |
| Mechanical Design | Compact plug-in chassis for cabinet rack mounting |
| Compliance Certifications | CE, UL, CSA, RoHS industrial compliance |
| Matching Rectifier Unit | Matched with 6SE70 series 890–930V DC regenerative / passive rectifier |
| Typical Application | Large extruders, rolling mills, paper machines, heavy conveyor main drives |
