2711-T14C8
The 2711-T14C8 operator interface terminal has been manufactured as part of the Panelview 1400 series by Allen-Bradley/Rockwell Automation. It can support color graphics on its touch and display screen. The screen on the 2711-T14C8 operator interface terminal is 14 inches wide. It uses AC power and it supports the DH+ industrial communication network. The 2711-T14C8 operator interface terminal also supports connection to a printer through its RS-232 printer port.
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 2711-T14C8 |
| Power Type | AC |
| Supply Voltage Limit | 85-264 Volts; 43-63 Hertz |
| Power Consumption | 200 VA max |
| Comm Port | DH+ |
| Total Application Flash Memory | 1008 Kbytes |
| Operating Shock | 15 g |
| Non-Operating Shock | 30 g |
| Operating Temperature | 32-131 F (0-55 C) |
| Dimensions | 13.97 x 17.37 x 15.53 in (355 x 441 x 394 mm) |
| Display Dimensions | 10.0 x 7.5 in (255 x 191 mm) |
| Weight | 43.2 lbs (19.6 kg) |
| Operator Input | Touchscreen |
