6DR5120-0NG03-0AA2
Image similar
SIPART PS2 Smart, electropneumatic positioner, 4…20mA, HART, Ex/nEx, double-acting, polycarbonate enclosure, for pneumatic linear and part-turn actuators. Non-contacting (wear-free) position detection (NCS). Standard Without explosion protection. Connection thread el.: M20x1.5 / pneu.: G 1/4 Without limit monitor. Analog Output Module (AOM) and Analog Input Module (AIM). The internal position detection via a potentiometer is not applied but can be ordered in addition with ‑Z K11. Device plug M12 is not available. Isolating power supply SITRANS I100 separately orderable (7NG4124-1AA00). . Brief instructions English / German / Chinese. Standard / Fail-Safe – Depressurizing the actuator in case of failure of electrical auxiliary power (single acting only). Manometer block aluminumG¼, double-acting with plastic manometer IP31 (MPa, bar)
| Product | |
| Article Number (Market Facing Number) | 6DR5120-0NG03-0AA2 |
| Product Description | SIPART PS2 Smart, electropneumatic positioner, 4…20mA, HART, Ex/nEx, double-acting, polycarbonate enclosure, for pneumatic linear and part-turn actuators. Non-contacting (wear-free) position detection (NCS). Standard Without explosion protection. Connection thread el.: M20x1.5 / pneu.: G 1/4 Without limit monitor. Analog Output Module (AOM) and Analog Input Module (AIM). The internal position detection via a potentiometer is not applied but can be ordered in addition with ‑Z K11. Device plug M12 is not available. Isolating power supply SITRANS I100 separately orderable (7NG4124-1AA00). . Brief instructions English / German / Chinese. Standard / Fail-Safe – Depressurizing the actuator in case of failure of electrical auxiliary power (single acting only). Manometer block aluminumG¼, double-acting with plastic manometer IP31 (MPa, bar) |
| Series name | SIPART PS2 |
| positioner | |
| 4…20mA, HART, Ex/nEx | |
| double-acting | |
| polycarbonate enclosure | |
| G 1/4 Without limit monitor | |
| Protection Level | IP31 |
| Warranty | 1 YEAR |
| Net Weight (kg) | 1,570 Kg |
| Packaging Dimension | Not available |
| Country of origin | France |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | 90328100 |
| LKZ_FDB/ CatalogID | FI01-5 |
| Product Group | 4759 |
| Group Code | R3P2 |
