6AG4010-5EC33-0XJ5
| Parameter | Value |
|---|---|
| Order Number | 6AG4010-5EC33-0XJ5 |
| Product Family | SIMATIC IPC3000 SMART Compact (Small Chassis) |
| Form Factor | 19” Rack PC, 4U height, compact chassis |
| Processor | Intel Core i5-4570S (4C/4T, 3.6 GHz, 6 MB cache) |
| Chipset | Intel H81 |
| Main Memory | 4 GB DDR3 SDRAM (1×4 GB), dual-channel |
| Storage | 1 TB SATA HDD (internal, 3.5”) |
| Optical Drive (ODD) | Without ODD |
| Power Supply | 100–240 V AC, 50/60 Hz, 350 W industrial PSU |
| Ethernet Interfaces | 2× Gbit LAN (RJ45, Intel® I210) |
| Serial Ports | 4× COM: 2× RS-232/422/485; 2× RS-232 |
| USB Ports | Rear: 8× USB 2.0; Front: 2× USB 2.0 |
| Video Outputs | 1× VGA; 1× DVI-D (dual-display capable) |
| Peripheral Interfaces | 2× PS/2; Audio (line-in/out, mic) |
| Expansion Slots | 5× long slots: 2× PCIe x1, 1× PCIe x8, 1× PCIe x16, 1× PCI |
| Operating System | Without OS (field-installable) |
| Environmental Rating | Operating temp: 0°C ~ +40°C; Shock: 1 g, 20 ms; Vibration: 0.2 g |
| Dimensions (W×H×D) | 434 mm × 177 mm × 356 mm (compact depth) |
| Weight | ~14.5 kg |
| Certifications | CE, FCC, RoHS; China market exclusive (JJS OEM) |
| Special Notes | EOL (End-of-Life) – no replacement |
