6ES7647-8BA14-0LA3
SIMATIC IPC227E (Nanobox PC); 1x display port; 2x 10/100/1000 Mbit/s Ethernet RJ45; 1 x USB3.0, 3 x USB2.0; CFast slot; 24 V DC industrial power supply Celeron N2807 (2C/2T) 2 GB RAM; Box: PCIE with COM 1/2 without operating system 8 GB CFAST; without SIMATIC software Vertical mounting
| Parameter Item | Technical Specification |
|---|---|
| Order Number | 6ES7647-8BA14-0LA3 |
| Product Model | SIMATIC IPC227E Nanobox Box PC |
| Video Interface | 1 × DisplayPort |
| Network Ports | 2 × 10/100/1000 Mbps Gigabit Ethernet RJ45 |
| USB Interfaces | 1 × USB3.0 + 3 × USB2.0 |
| Storage Slot | 1 × CFast slot |
| Built-in Storage | 8 GB CFast memory card |
| Power Input | 24 V DC industrial power supply |
| CPU Processor | Intel Celeron N2807 (2-core 2-thread, 1.58 GHz) |
| System RAM | 2 GB DDR3L SO-DIMM memory |
| Serial Interface | Equipped with COM1 + COM2 serial ports |
| Expansion Slot | Integrated PCIe slot |
| Pre-installed OS | No factory preloaded operating system |
| Bundled Software | Without SIMATIC automation software suite |
| Mounting Type | Vertical cabinet mounting |
| Enclosure Protection Class | IP40 dust-proof cabinet housing |
| Dimensions | 191 mm × 100 mm × 60 mm |
| Weight | Approx. 1.9 kg |
| Operating Temperature | 0 ℃ ~ +60 ℃ |
| Monitoring Functions | Temperature monitoring, watchdog, status LED indicators |
| Global Certifications | CE, UL, cULus, FCC Class A, RCM, KC, EAC |
| Product Lifecycle | Phase-out announced since 31.07.2025 |
| Origin | Germany |
