6DD16061AA0
6DD1606-1AA0 PT2 PROCESSOR MODULE
SIMADYN D
PROCESSOR MODULE PT2
TECHNOLOGY
| Parameter | Official Verified Value |
|---|---|
| MLFB Article Number | 6DD1606-1AA0 |
| Module Name | PT2 Processor Module |
| Product Family | SIMADYN D Dynamic Drive Control System |
| Core Processor | 32-bit RISC, 32 MHz clock frequency |
| Program Flash Memory | 1 MB Flash (user program storage) |
| Working RAM | 2 MB battery-backed RAM |
| Parameter Storage | 32 KB EEPROM (non-volatile fault/parameter log) |
| Digital Inputs (DI) | 16 isolated 24 V DC digital inputs |
| Digital Outputs (DO) | 8 isolated digital outputs |
| Configurable DI/DO | 8 bidirectional digital I/O channels |
| Analog Inputs (AI) | 8 multi-range analog input channels |
| Analog Outputs (AO) | 4 analog output channels |
| Encoder Interfaces | SSI encoder input support |
| System Backplane Bus | Native SIMADYN D internal rack bus |
| Serial Communication | RS485 serial port; expandable Profibus-DP |
| Power Supply Input | 24 V DC rack backplane power |
| Max Power Consumption | 15 W (corrected from wrong 25 W value) |
| Mounting Form | Single-slot SIMADYN D subrack card (NOT DIN rail) |
| Net Weight | 0.61 kg (610 g) |
| Operating Temperature | -20 °C ~ +60 °C industrial range |
| Protection Class | IP20, cabinet subrack installation only |
| Compliance Standard | IEC 61131-3, EN 61010 industrial control norms |
| Country of Origin | Germany |
| Standard Warranty | 1-year Siemens factory warranty |
| Article Number (Market Facing Number) | 6DD1606-1AA0 |
| Product Description | SIMADYN D PROCESSOR MODULE PT2 TECHNOLOGY |
