Technical Specifications for 2711-T5A5L1
| Backlight | 100,000 hr LED backlight life | Heat Dissipation: | 20 W (69 BTU/HR) f |
| Software | PanelBuilder32 | Part Number/Catalog No. | 2711-T5A5L1 |
| Input Type | Touch | Product Line | Panelview 550 |
| Brand | Allen-Bradley | Display Size | 5.5 in. |
| Manufacturer: | Rockwell Automation | Display Color | Monochrome LCD blue mode |
| Product Family: | PanelView Standard Terminals | Communication | RS-232 (DH-485) Communication Port |
| Product Type: | PanelView 550 Standard Operator Terminals | Input Power | 24V DC |
| Display Type: | Liquid Crystal Display (LCD) | Memory | 170 KB application runtime |
| Display Area: | 120 x 60 mm (4.75 x 2.38 in.) | Communication Cable | 2711-NC13 |
| Resolution: | 256 x 128 | Shipping Weight | 5 lbs |
| Touchscreen: | 128 (16 columns x 8 rows) | Shipping Dimensions | 14x11x8 inches |
| Touch Cell size: | 26 x 30 pixels | Series | A,B,C,D,E,F,G,H |
| Application memory: | 170 KB application runtime; 240 KB nonvolatile RAM (application objects plus text and bitmaps) | Firmware | 1.00-4.48 |
| Communication ports: | RS232 (DH485) | UPC | 10611320019473 |
| Input Voltage range: | 18…30V DC (24V DC nominal) | Product Lifecycle Status* | Discontinued/Obsolete |
| Operating Temperature: | 0…55 ° C (32…131 ° F) |
