ACS580-04-505A-4
| General Information | Global Commercial Alias | ACS580-04-505A-4 |
| Product ID | 3AUA0000170509 | |
| ABB Type Designation | ACS580-04-505A-4 | |
| EAN | 6438177340423 | |
| Catalog Description | ACS580-04-505A-4 PN: 250 kW, IN: 505 A | |
| Long Description | The ACS580-04 is plug-in ready to control compressors, conveyors, pumps, extruders, centrifuges, mixers, fans and many other variable and constant torque applications, in a variety of light industries, including food and beverage, plastic, textile, material handling, and agriculture. All essential features are built-in as standard, simplifying drive selection, and making additional hardware unnecessary. Versatile and straightforward settings menu and assistants enable fast setup, commissioning, use and maintenance, while rugged and robust design makes it a good fit for various environments. With the ACS580 drives you can easily take full control of your processes to comprehensively manage your plant. The ACS580-04 drive module comes in IP00 enclosure as standard for cabinet installation. Also, IP20 enclosure is available. | |
| Ordering | Country of Origin | Finland (FI) |
| Container Information | Gross Volume | 0.19 m³ |
| Dimensions | Product Net Weight | 162 kg |
| Product Net Height | 1462 mm | |
| Product Net Length | 529 mm | |
| Product Net Width | 350 mm | |
| Package Level 1 Depth / Length | 2060 mm | |
| Package Level 1 Height | 500 mm | |
| Package Level 1 Width | 670 mm | |
| Package Level 1 Units | 1 carton | |
| Technical | Number of Phases | 3 |
| Degree of Protection | IP00 | |
| Enclosure Type NEMA | Open Type | |
| Frequency (f) | 50/60 Hz | |
| Input Voltage (Uin) | 380 … 480 V | |
| Mounting Type | Module for cabinet building | |
| Output Current, Heavy-Duty Use | 361 A | |
| Output Current, Light-Overload Use | 485 A | |
| Output Current, Normal Use | 505 A | |
| Output Power, Heavy-Duty Use | 200 kW | |
| Output Power, Light-Overload Use | 250 kW | |
| Output Power, Normal Use | 250 kW | |
| Apparent Power Output | 350 kV·A | |
| Efficiency Level | IE2 | |
| Standby Loss | 396 W | |
| Temperature Rating | Maximum 40 °C | |
| Additional Information | Product Main Type | ACS580-04 |
| Product Name | Frequency converter |
