600.0 HP Yaskawa A1000 Series IP00 Open Chassis Variable Frequency Drive | 400 – 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 930.0 Amps | CIMR-AU4A0930AAA
| Parameter Item | Official Specification Value |
|---|---|
| Full Article Number | CIMR-AU4A0930AAA |
| Product Series | A1000 High Performance Vector Control AC Drive |
| Model Code Definition | AU: Flange cold plate mounting (NEMA 12 rear heat sink); 4: 400V 3-phase class; 0930: 930A ND rated output; AAA: Standard spec, no built-in EMC filter |
| Input Power Supply | 3-phase AC 380–480 V, 50/60 Hz, voltage tolerance -15% ~ +10% |
| Rated Output Current (ND Normal Duty, Variable Torque) | 930 A |
| Rated Output Current (HD Heavy Duty, Constant Torque) | 810 A |
| Max Applicable Motor Power (ND) | 500 kW / 670 HP |
| Max Applicable Motor Power (HD) | 450 kW / 600 HP |
| Overload Capacity | ND: 120% rated current for 60 s; HD: 150% rated current for 60 s |
| Max Adjustable Output Voltage | 0–480 V 3-phase AC |
| Output Frequency Range | 0.01–400 Hz |
| Carrier Frequency | 2–8 kHz user configurable (power derating above 2kHz) |
| Control Modes | Open-loop V/f, Closed-loop V/f, Open-loop vector, Closed-loop vector, PM motor vector control |
| Cooling Structure | Flange cold plate heat dissipation, heat sink extends outside cabinet, fanless internal |
| Built-in EMC Filter | Not equipped, external EMC filter required for CE EMC compliance |
| Built-in Brake Transistor | None; external braking unit & resistor mandatory |
| Compatible Motor Types | 3-phase induction/asynchronous motor, permanent magnet synchronous motor |
| Regenerative Function | Supported via optional external regenerative feedback unit |
| Standard Onboard Communication Ports | MODBUS Slave, Serial RS-422, Serial RS-485 |
| Optional Communication Cards | CANopen, DeviceNet Slave, EtherCAT Slave, EtherNet/IP, MECHATROLINK II, MODBUS/TCP, POWERLINK, PROFIBUS DP, PROFINET |
| Standard I/O Terminals | 8 multi-function 24VDC digital inputs; 3 analog inputs; 1 pulse input; 4 relay digital outputs; 2 analog outputs; 1 pulse output |
| Safety Function | STO Safe Torque Off, SIL 2 / PL d safety compliance |
| Enclosure Protection Grade | IP00 chassis (cabinet interior); rear flange heat sink NEMA 12 |
| Overall Dimensions (W × H × D) | 1250 mm × 1380 mm × 370 mm |
| Net Weight | 545 kg |
| Continuous Operating Ambient Temp | -10 °C ~ +40 °C full rated load; -10 ~ +50 °C with power derating |
| Storage & Transportation Temperature | -20 °C ~ +60 °C |
| Relative Humidity | 5%–95% RH, non-condensing, no icing |
| Installation Altitude | Full power up to 1000 m; derate 1% per 100 m, max 3000 m |
| Vibration Resistance | 10–20 Hz: 9.8 m/s²; 20–55 Hz: 2.0 m/s² (large frame high-power spec) |
| Hardware Protection Functions | Overcurrent, overvoltage, undervoltage, overheat, motor overload, earth fault, output short circuit |
| Global Certifications | UL, cUL, CE, UKCA, GL Marine, RoHS 2.0 compliant |
