Brand: Rockwell Automation / Allen-Bradley
Allen-Bradley 2711-K10C3 is a PanelView 1000 Standard Operator Terminal.
PV1000 COLOR KEY, DH485 & RS232 PRINT WITH DH-485 COMMUNICATION & RS-232 PRINTER PORT
| Technical specifications for 2711-K10C3 | |
| Weight: | 3.7 kg (8.2 lb) |
| Accessories: | function key legend inserts; Anti-glare overlays; backlight replacements; Real-time clock replacements; Mounting hardware; Power supply and terminal block; interface modules; |
| Input Voltage range: | 85…264V AC, 47…63 Hz |
| Communication ports: | DH485; RS232 (Printer) |
| ATA memory card: | Supported |
| Application memory: | 310KB application runtime; 1008 KB nonvolatile memory (application objects plus text and bitmaps) |
| Keypad function keys: | 16 function keys (F1…F16) |
| Backlight: | 50,000 hr 1/2 life at 25 °C (77 °F) |
| Resolution: | 640 x 480 |
| Display Area: | 211 x 158 mm (8.3 x 6.2 in.) |
| Display Type: | Color active matrix TFT |
| Manufacturer: | Rockwell Automation |
| Product Family: | PanelView Standard |
| Product Type: | PanelView 1000 Operator Interface |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 2711-K10C3 |
| Product Line | Panelview 1000 |
| Display Size | 10.1 in. |
| Display Color | Multi-Color |
| Input Type | Keypad |
| Communication | DH-485 |
| Input Power | 85-264 Volts Alternating Current |
| Memory | 256 Kilobytes |
| Enclosure Type | NEMA Type 12/13 or 4X |
| UPC | 10662072718541 |
| Product Lifecycle Status* | Discontinued/Obsolete |
