ABB Frequency converter ACS880-01-084A-7 75kW 84A

• Country of Origin:

  Finland (FI)

• Customs Tariff Number:

  85044088

• Invoice Description:

  ACS880-01-084A-7 PN: 75 kW, IN: 84 A

• Made To Order:

  Yes

• Minimum Order Quantity:

  1 piece

• Order Multiple:

  1 piece

• Quote Only:

  No

• Selling Unit of Measure:

  piece

Container Information

• Gross Volume:

  65.404 dm³

Dimensions

• Product Net Weight:

  42.2 kg

• Product Net Depth / Length:

  357 mm

• Product Net Height:

  727 mm

• Product Net Width:

  252 mm

• Package Level 1 Depth / Length:

  880 mm

• Package Level 1 Height:

  536 mm

• Package Level 1 Width:

  335 mm

• Package Level 1 Units:

  1 carton

Technical

• Number of Phases:

  3

• Degree of Protection:

  IP21

• Enclosure Type NEMA:

  Type1

• Sound dB (A):

  68 dB(A)

• Frequency (f):

  50/60 Hz

• Input Voltage (U_in):

  525 … 690 V

• Mounting Type:

  Wall-mounted

• Communication Protocol:

  MODBUS
  DeviceNet
  PROFIBUS
  PROFIsafe
  CAN
  EtherNet/IP
  PROFINET IO
  TCP/IP
  Other Bus Systems

• Number of Hardware Interfaces:

  Industrial Ethernet 0
  PROFINET 0
  RS-232 0
  RS-422 0
  RS-485 1
  Serial TTY 0
  USB 1
  Parallel 0
  Other 6

• Includes:

  With control unit
  Without optical interface
  With PC connection

• Analog Inputs:

  2

• Analog Outputs:

  2

• Number of Digital In/Outputs:

  6/5

• Output Current, Heavy-Duty Use:

  61 A

• Output Current, Light-Overload Use:

  80 A

• Output Current, Normal Use:

  84 A

• Output Power, Heavy-Duty Use:

  55 kW

• Output Power, Light-Overload Use:

  75 kW

• Output Power, Normal Use:

  75 kW

• Apparent Power Output:

  100 kV·A

• Efficiency Level:

  IE2

• Standby Loss:

  76 W

• Complete Drive Module Efficiency (61800-9-2):

  Operating Point Frequency / Current	Absolute Loss	Relative Loss	Efficiency
  0 / 25 %	405 W	0.4 %	93.1 %
  0 / 50 %	550 W	0.5 %	95.0 %
  0 / 100 %	847 W	0.8 %	96.1 %
  50 / 25 %	442 W	0.4 %	96.3 %
  50 / 50 %	622 W	0.6 %	97.2 %
  50 / 100 %	983 W	1.0 %	97.8 %
  90 / 50 %	706 W	0.7 %	98.2 %
  90 / 100 %	1303 W	1.3 %	98.4 %

• Temperature Rating:

  Maximum 40 °C

Additional Information

• Product Main Type:

  ACS880-01

• Product Name:

  Frequency converter
