ABB Frequency converter ACS580-07-0880A-4 500KW 880A

• Country of Origin:

  Finland (FI)
  Estonia (EE)

• Customs Tariff Number:

  85044084

• Invoice Description:

  ACS580-07-0880A-4 PN: 500 kW, IN: 880 A

• Made To Order:

  Yes

• Minimum Order Quantity:

  1 piece

• Order Multiple:

  1 piece

• Quote Only:

  No

• Selling Unit of Measure:

  piece

Container Information

• Gross Volume:

  1.243 m³

Dimensions

• Product Net Weight:

  440 kg

• Product Net Depth / Length:

  698 mm

• Product Net Height:

  2315 mm

• Product Net Width:

  965 mm

• Package Level 1 Depth / Length:

  1100 mm

• Package Level 1 Height:

  2550 mm

• Package Level 1 Width:

  1430 mm

Technical

• Number of Phases:

  3

• Degree of Protection:

  IP21

• Enclosure Type NEMA:

  Type1

• Sound dB (A):

  71 dB(A)

• Frequency (f):

  50/60 Hz

• Input Voltage (U_in):

  380 … 480 V

• Mounting Type:

  Cabinet-built

• Output Current, Heavy-Duty Use:

  725 A

• Output Current, Light-Overload Use:

  865 A

• Output Current, Normal Use:

  880 A

• Output Power, Heavy-Duty Use:

  400 kW

• Output Power, Light-Overload Use:

  500 kW

• Output Power, Normal Use:

  500 kW

• Ecodesign Exemption:

  Energy efficiency data is not provided for this cabinet-based drive. Cabinet built drives, with already conform modules, are excluded from the scope of the EU ecodesign requirements (Regulation EU/2019/1781, §2.3.e).

Additional Information

• Product Main Type:

  ACS580-07

• Product Name:

  Frequency converter
