SIMOVERT MASTERDRIVES VC CHASSIS UNIT/IP00;WATER COOLED AC 380-460V/50/60HZ 186A
| Parameter Category | Specification |
|---|---|
| Model Number | 6SE7031-8EF20-1AA0 |
| Product Series | SIMOVERT MASTERDRIVES VC (Vector Control) |
| Type | Water-Cooled Inverter Unit (Chassis Mount, IP00) |
| Input Voltage | 3AC 380–460 V, 50/60 Hz |
| Rated Output Power | 90 kW |
| Rated Output Current | 186 A |
| Output Frequency Range | 0–500 Hz |
| DC Link Voltage | 510–650 V DC |
| Cooling Method | Water-cooled |
| Protection Rating | IP00 |
| Dimensions (W×H×D) | 360 mm × 1060 mm × 350 mm |
| Weight | 65 kg |
| Ambient Temperature (Operation) | 0 °C to +40 °C |
| Altitude Rating | ≤1000 m (derating required above 1000 m) |
| Control Mode | Vector Control (VC), V/f Control |
| Overload Capacity | 136% for 1 minute; 150% for short duration |
| Status | Obsolete / Discontinued |
