Technical Specifications for 2711-B6C5
Backlight 50,000 hr 1/2 life at 25 °C (77 °F)
Input Type Keypad / Touch
Brand Allen-Bradley
Manufacturer: Rockwell Automation
Product Family: PanelView Standard Terminals
Product Type: Operator Terminals
Display Type: Color active matrix TFT
Display Area: 115 x 86 mm (4.54 x 3.4 in.).
Resolution: 320 x 234
Touchscreen: Touch cells: 128 Actuation: 1 million presses
Keypad function keys: 10 function keys (F1…F10)
Application memory: 170 KB application runtime; 240 KB nonvolatile memory (application objects plus text and bitmaps)
Communication ports: RS232 (DH485)
Input Voltage range: 85…264V AC, 47…63 Hz
Accessories: function key legend inserts; Anti-glare overlays; backlight replacements; Real-time clock replacements; Mounting hardware; Power supply and terminal block; interface modules;
Part Number/Catalog No. 2711-B6C5
Product Line PanelView 600
Display Size 5 inches
Display Color Color
Communication RS-232 (DH-485)
Input Power 85 to 264 Volts AC
Software Panelbuilder 32
Memory 240 KB
Communication Cable 2711-NC14
Shipping Weight 6 pounds
Shipping Dimensions 14 x 11 x 8 inches
Series A, B, C, D, E, F, G, H, I, J, K, and L
Firmware 1.00 to 4.48
UPC 10662072660222
Product Lifecycle Status* Discontinued/Obsolete
