20G11ND065AA0NNNNN — PowerFlex Air Cooled 755 AC Drive
Allen-Bradley PowerFlex Air Cooled 755 AC Drive
| Manufacturer | Allen-Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 755 |
| Part Number | 20G11ND065AA0NNNNN |
| UPC | 884951037939 |
| Weight | 60.00 lbs (27.22 kg) |
| Input Type | AC Input with Precharge (includes DC terminals) |
| Enclosure | IP00 / IP20 / NEMA Open / NEMA 1 |
| Voltage Rating | 480 VAC / 650 VDC |
| Line Frequency | 50/60 Hz |
| ND Current Rating | 65 A |
| Power Output (HP) | 50 HP |
| Power Output (kW) | 37 kW |
| Frame Size | 5 |
| Filtering | Yes |
| Default CM Cap Configuration | Jumper Removed |
| Dynamic Braking | Internal Transistor |
| Door Mounted HIM | None |
| Operating Temperature | 0 to 40 °C (32 to 104 °F) |
| Storage Temperature | -40 to 70 °C (-40 to 158 °F) |
