1794-ASB
ALLEN-BRADLEY Remote Flex I/O Adapter Installation Instructions
Installation Instructions
| Technical specifications for 1794-ASB | |
| Manufacturer | Allen Bradley |
| Product Type | Remote IO Adapter |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-ASB |
| UPC | 662468112178 |
| Weight | 0.38 lbs (0.17 kg) |
| Power Dissipation | 4.6 W @ 31.2V DC |
| Product Description | Remote I/O communication Adapter |
| Communication Port | One (1) RIO port |
| Supported Protocol | RIO |
| Supported topologies | Daisy Chain |
| Data Transfer speed | 57.6Kbps, 115.2Kbps, and 230.4kbps |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Vibration | Tested 5 g @ 10-500Hz per IEC 68-2-6 |
| Operating Shock | 30 g peak acceleration, 11(+1)ms pulse width |
| Power Consumption | 330 mA @ 24V DC |
| Thermal Dissipation | 15.7 BTU/hr @ 24V DC |
| Series | Flex I/O |
| Module Capacity | 8 Modules |
| Mount | DIN Rail |
| Controller Platform | FlexLogix |
| Diagnostic Indicators | Status |
| Enclosure | IP20, Open Type |
| Series Available | 1794-ASB – A/B/C/D/E |
| Communication Rate | 57.6, 115.2, 230.4 Kbps |
| External Power Supply | 450 mA at 24 Volts DC |
| Voltage | 24 Volts DC |
