| Item | Specification |
|---|---|
| Article Number | 1769‑IF8 |
| Manufacturer | Allen‑Bradley (Rockwell Automation) |
| Product family | 1769 CompactLogix Compact I/O Modules |
| Number of channels | 8 analog input channels, single‑ended or differential configurable |
| Analog input ranges | Voltage: ±10 V, 0‑10 V, 0‑5 V, 1‑5 V
Current: 0‑20 mA, 4‑20 mA |
| ADC converter type | Sigma‑Delta |
| Resolution | 16‑bit unipolar; 15‑bit plus sign bipolar |
| Backplane current draw | 120 mA @ 5 VDC; 70 mA @ 24 VDC |
| Power dissipation | 3.24 W total |
| Isolation | 500 V AC reinforced isolation between field side and backplane |
| Operating ambient temperature | 0 … +60 °C |
| Storage temperature | -40 … +85 °C |
| Relative humidity | 5‑95 % non‑condensing |
| Wire size | 22‑14 AWG solid, 22‑16 AWG stranded copper wire |
| Dimensions (H × W × D) | 118 × 35 × 87 mm (4.65 × 1.38 × 3.43 in) |
| Net Weight | 0.29 kg |
| Mounting | DIN‑rail or panel mount, occupies 1 Compact I/O slot |
| Degree of protection | IP20 (cabinet‑internal module) |
| Certifications | UL 508, C‑UL, CE, Class I Div 2 hazardous location certified |
| Warranty | 1 YEAR |
| Country of origin | Malaysia |
